Schneider Solar Home Elevator
Today, a house’s consumption of energy from non-renewable sources negatively impacts the environment. Our goal is to reduce consumption as well as to push for the use of alternative energy sources. The Schneider Solar Home Elevator gets us closer to realizing this goal. It replaces the use of grid energy as a main source with a renewable source – sunlight.
BENEFITS OF SCHNEIDER SOLAR HOME ELEVATOR
AVAILABILITY. Continuous operation even in the event of power cut.
RELIABILITY. Solar elevator based on the successful annd Reliable Schneider S820 Home Elevator.
CLEAR ENERGY BALANCE. Optimazed energy supply with solar energy as the main source.
ENERGY REGENERATION. Energy is regained to charge the Energy Storage Device.
EASY INTEGRATION. Continuous operation even in the event of power cut.
EFFECIENT AND RELIABLE OPERATION.
The elevator uses a smart power supply – renewable energy from sunlight and a back-up from the grid. Schneider’s Power Manager (PM) optimizes the use of clean solar energy by controlling the energy distribution. It lowers energy costs by making sure that the Energy Storage Device is charged with solar energy as much as possible.
Single Phase
(Plug-in Mode)
PV Panels
(Solar Mode)
Power Manager
Schneider Home Lift
Energy Storage Device
SCHNEIDER SOLAR HOME ELEVATOR
Elevator System
Schneider S820 Home Elevator
Capacity
250 - 400 kg, 3-5 passengers
Entrace (mm)
Door Opening Style
700(w)*2000(h)
Center opening or Side opening
Travel Height
12 meter, 4 floors
Speed
0.4 (m/s)
Driver System
Machine-room less with Schneider Gearless frequency controlled drive system
Car Dimension
900*1200 | 1000*1200 | 1200*1200
Shaft Dimension
1500*1550 | 1650*1550 | 1850*1550
Overhead Requirement
3200 (mm)
Pit depth Requirement
450 (mm)
Power Supply
AC 220V 50Hz
